GoodWe’s 3-phase smart meter GM3000
For GoodWe grid voltage inverters of the XS, DNS, SDT G2 and SMT series, the 3-phase smart meter GM3000 can be ordered separately. The meter monitors voltage, current, power and energy at the grid connection point. The data can be retrieved via the SEMS portal.
Product Features
- With LED
- Own consumption: < 3 W
- Interface: USB
- Communication with inverters: RS485
- Operating temperature: -20 – 60°C
- Dimensions: 85 x 36 x 66.5 mm (H x W x D)
- Weight: 0.42 kg
- IP 20
